 Release status: stable |
|
|---|---|
 |
|
| Implementation | User interface |
| Description | Provides access to the Proton service for browser-based PDF rendering |
| Author(s) | Wikimedia Germany (WMDE) – Roadmap |
| Latest version | continuous updates |
| Compatibility policy | Snapshots releases along with MediaWiki. Master is not backward compatible. |
| MediaWiki | 1.25+ |
| Database changes | No |
| License | GNU General Public License 2.0 or later |
| Download | Download extension Git [?]: |
| Example | Wikipedia article |
|
Parameters
|
|
|
Hooks used
|
|
| Quarterly downloads | 35 (Ranked 135th) |
| Public wikis using | 857 (Ranked 301st) |
| Translate the ElectronPdfService extension if it is available at translatewiki.net | |
| Issues | Open tasks · Report a bug |
The ElectronPdfService extension provides access to the Proton service for browser-based PDF rendering. (Proton needs to be installed separately.)
Historically, this extension provided access to the now defunct Electron PDF Service instead of Proton, hence its name.
Description
The extension provides a handy way to access the Proton service via a {{ll|RESTBase|RESTBase API endpoint}}.
And here's an example: PDF for the article about Berlin.
Installation
- Install Proton
- Install RESTBase, and set up a config similar to config.example.wikimedia.yaml. Adjust the PDF server URL to reflect your host & port.
- Download and place the file(s) in a directory called
ElectronPdfServicein yourextensions/folder. - Add the following code at the bottom of your LocalSettings.php file:
wfLoadExtension( 'ElectronPdfService' ); $wgElectronPdfServiceRESTbaseURL = '/api/rest_v1/page/pdf/';
Done – Navigate to Special:Version on your wiki to verify that the extension is successfully installed.
Usage
- Once the extension is installed, the “⧼ElectronPdfService-download-label⧽” link in the MediaWiki sidebar will lead you to a new selection screen.
- Click the “⧼ElectronPdfService-download-button⧽” button to get the PDF.
- Note: if there is no alternative rendering method available on the Wiki, “⧼ElectronPdfService-download-label⧽” will immediately serve you the Proton rendered PDF without showing a selection screen.
Links
- RESTBase API documentation
- Example PDF
See also
- PDF export – summary of all PDF export extensions
- Read more on the background of the motivation for the extension and the service.
